Fantom 1500VA / 720W UPS

• Capacity: 1500VA/720W

INPUT:

• Voltage: 220/230/240Vac

• Voltage Range: 140~300Vac

• Frequency Range: 50/60Hz (Auto sensing)

OUTPUT (Batt. Mode):

• AC Voltage Regulation: ±10%

• Frequency Range : 50/60Hz ±1 Hz

• Transfer Time: Typical 4-8ms, 13ms Max.

• Waveform: Simulated Sinewave

BATTERY:

• Battery Voltage: 12Vdc

• Battery Type & Number: 12 V/7Ah×2

• Typical Recharge Time: 6~8 hours recover to 90% capacity

INDICATORS:

• LED Display: AC Mode, Battery Mode, Overload, Fault

PROTECTION:

• Full Protection: Short circuit, Overload, Overcharge and Overdischarge

OPERATING ENVIRONMENT:

• Humidity: 0-90 % RH @ 0- 40°C (Non-condensing)

• Noise Level: Less than 55dB

PHYSICAL:

• Approx. Dimension (D×W×H ): 353×149×162mm

• Approx. Net Weight: Approx. 8.4kg
